Power Equipment SPZ-52H-27CX
$0.00
Title
Power Equipment SPZ-52H-27CX
Categories :
Scag
52" Hero Cutter Deck, 27 HP Briggs CXi Series™ - V-Twin
FEATURES
Command perfection - DEEP, FABRICATED, AND WELDED CUTTER DECKS: Heavy-duty Hero Cutter Deck design and construction yield an excellent quality-of-cut. Deep design handles lots of grass at higher speeds. Heavy-duty, aluminum, sealed ball bearing, blade-drive spindles provide reliable performance season after season.
Ogura PTO Clutch Brake - Strong, Adjustable Clutch for Long Life: The Ogura GT2 PTO Clutch Brake provides excellent starting and stopping power for the cutter deck, 108 ft. lb. of holding strength, and an adjustable air gap for long life.
Foot-Pedal Parking Brake - Stay in Control: Foot-operated parking brake activates a disc-brake system, allowing the parking brake to be engaged without taking your hands off of the steering controls. Ausco disc brakes provide reliable performance.
Iso-Mounted Footplate - Crank Up the Comfort: Pierced, extruded-steel footplate is rubber iso-mounted for enhanced comfort.
Low-Maintenance Mower Design - More Uptime: Fewer grease points increase operator convenience and ease-of-ownership.
Hydro-Gear ZT-3100 / ZT-3400 Transaxles - Speeds Up To 10 MPH (SPZ61) / 8.5 MPH (SPZ52): The ZT drive systems' dual hydro transaxles with all-metal gears and spin-on oil filters deliver smooth, solid power to the drive wheels. Large cooling fans keep temperatures low and extend component life.
Suspension Seat - Ride in Comfort: The torsion-spring suspension seat adjusts to each operator's weight, is contoured and features armrests, all to provide superior comfort.
High-Strength Steel Frame - Solid Design for Years of Dependable Service: Tubular-steel main frame delivers unmatched strength and longevity.
Powerful and Efficient Engine Options - Reliable Power, Up To 26 HP: Choose from a Briggs Vanguard™, Kawasaki® FX or a Kohler® Command PRO® air-cooled, V-twin engine.
SPECIFICATIONS
Description: 52" Hero Cutter Deck, 27 HP Briggs CXi Series™ - V-Twin
Total Fuel Capacity: 6.5 gallons
Drive Tires: 22" x 10.5"-12" (52"); 24" x 12"-12" (61")
Caster Tires: 13" x 6.5"-6"
Seat: Torsion-spring suspension seat
Drive System Type: Hydro-Gear ZT3100 Transaxle (52"); Hydro-Gear ZT3400 Transaxle (61")
Pumps: ZT3100 Internal Pump: 10 cc (52"); ZT3400 Internal Pump: 12 cc (61")
Motors: Internal Motor: 16 cc
Forward Ground Speed: 8.5 mph (52"); 10 mph (61")
Reverse Ground Speed: 5 mph
Parking Brake: Foot-operated pedal
Cutting Widths: 52" and 61"
Type: Hero Cutter Deck
Cutting Height: 1.5" to 5" in .25" increments
Deck Lift: Foot-operated pedal
Construction: Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles.
Spindles: Aluminum housing with sealed ball bearings.
Blade Engagement: Ogura GT2 (108 ft lb); Adjustable air-gap for extended life.
DIMENSIONS
Length: 73"
Width (chute down): 64.5"
Width (chute in transport position): 53"
Height (ROPS folded): 46.5"
Height (ROPS up): 61"
Weight: 907-911 lb
ACCESSORIES
2-Bag Spindle Driven Grass Catcher
2-Bag Grass Catcher
Fabric Bag Grass Catcher
Hurricane Mulch System
Mulch Plate
Tiger Stripe Kit
Light Kit
Trailer Hitch
Chrome Wheel Covers
Flat-Free Caster Tire
Blade Buddy
